Technical data Instruction manual GSP
76 / 92 38107010002 en-US
9 Technical data
9.1 Dimensions GSP H with a carriage inclination of 0°
The machines are available in different versions. Figures show examples.
Fig.110: GSP H 0°
Dimensions Notes
Installation area (L x W) 532 x 478 mm / 20.9" x 18.8"
Maximum dimensions
(L x W x H)
770 x 769 x 567 mm / 30.3" x
30.3" x 22.3"
The work area of the ma-
chine includes the area
within the max. dimensions:
IP rating IP33
Product size Height: 246 mm / 9.7"
Width: 290 mm / 11.4"
Round: Ø 260 mm / 10.2"
Slice thickness 0 - 24 mm / 0 - 0.9"
0 - 3 mm / 0 - 0.1"
Infinitely adjustable
Fine adjustment
Blade diameter 350 mm / 13.8"
Blade speed 266 rpm
Blade position 40° angle
Carriage angle 0°

Bizerba GSP H Specifications

General

Type	Slicer
Blade Diameter	330 mm
Cutting Thickness	0 - 24 mm
Material	Anodized aluminum
Operation	Manual
Voltage	230 V
Frequency	50 Hz
Protection Class	IP33
