Machine and operating elements Instruction manual GSP
32 / 92 38107010002 en-US
5.2.1 HMI touchscreen GSP HD
Fig.19: HMI touchscreen GSP HD
Toggling between manual operation and automatic operation
Stroke width selection
Selection of number of carriage strokes
Direct selection keys for number of target slices
Increasing / reducing the number of slices by 5
Number of slices (target)
Number of slices (current)
Using your finger, wipe from right to left on
the touchscreen. The following adjacent im-
age comes up.
to service menu
Select a blade speed / blade speed for
sharpening
Fig.20: HMI touchscreen GSP HD
