Instruction manual GSP Operation
38107010002 en-US 53 / 92
The changed values are saved with <En-
ter>.
Press the upper right icon to exit the
menu without saving.
Fig.68: Number of carriage strokes
6.3 Slicing with product feed for tomatoes
The product feed for tomatoes allows double slicing of tomatoes or similar vegetable to be
sliced. The applied product fixation device holds the product in position during slicing pre-
venting the product from tipping over.
The product fences are irreversibly self-locking on their shaft and can be moved across the
full width of the carriage.
- Requirement:
- The product feed for tomatoes has been attached. [}27]
Position product on gauge plate of car-
riage between both product fences.
Fasten both sliders with fence on prod-
uct.
Using handle, swivel in product holder
and position it behind the product.
Switch on machine.
Set slice thickness at knob.
Using the handle, move carriage uni-
formly forth and back.
The slices drop onto the depositing area
or can be removed directly by hand.
Once the slicing process is completed
set slice thickness to "0".
Switch off machine.
Fig.69: Product feed for tomatoes
6.4 Slicing with vegetable hopper
The vegetable hopper with stomper is specially designed for vegetables of all kinds.
The product is moved by means of its own weight and the weight of the stomper to the blade.
- Requirement:
- The vegetable hopper has been attached. [}27]
