Machine and operating elements Instruction manual GSP
34 / 92 38107010002 en-US
5.3 Slice thickness adjustment
The slice thickness is adjusted by means of
the rotary knob. Infinitely adjustable up to 22
mm.
Large fine adjustment range between 0 to
3mm.
Recommendation: Turn dial beyond desired
value in order to return it to the desired
value.
A slice thickness setting below "0" unlocks
the tilting lock of the carriage (black mark-
ing). The carriage can only be tilted to the
outside in this setting. (e.g. for cleaning pur-
poses).
Fig.22: Slice thickness adjustment
Displaying of operating status (optional)
The different operating states are defined by means of the lighting of the scale ring.
No lighting Constantly
flashing green
Constantly
flashing red
Flashing red
No supply volt-
age or failure of
machine
Gauge plate
closed
Gauge plate
open
Gauge plate
open
Gauge plate closed
Blade off Blade rotates Blade off Blade rotates
5.4 Options
The options need to be selected when ordering a machine.
Only the Bizerba customer service can set them at a later point of time.
Option Blade start
After switching on <I> of the machine the blade starts running automatically.
Option Switching on at zero
The machine can only be switched on if the slice thickness setting at the knob is smaller/
equal"0".
Option automatic switch-off
In manual mode.
If the blade drive runs for n seconds (default 15 seconds) without the machine being used, its
is automatically switched off.
Blade motor and servo support are switched off.
Option setting zero
The machine switches off as soon as the slice thickess is set equal or smaller "0" and while
the blade motor runs.
