Bizerba GSP H User Manual

Technical data Instruction manual GSP
78 / 92 38107010002 en-US
Dimensions Notes
Blade speed 255 rpm
Blade position 40° angle
Carriage angle 18°
Dimensions packaging
(L x W x H)
820 x 700 x 823 mm / 32.3" x
27.6" x 32.4"
Weight Approx. 43 kg / 94.8 lb
approx. 50 kg / 110.2 Ib with packaging
Types of current, voltages,
power consumption
See identification plate
9.3 Dimensions GSP H with a carriage inclination of 25°
Fig.112: GSP H 25° L
Dimensions Notes
Installation area (L x W) 532 x 478 mm / 20.9" x 18.8"
Maximum dimensions
(L x W x H)
809 x 906 x 574 mm / 31.9" x
35.7" x 22.6"
GSP 25° L
The work area of the ma-
chine includes the area
within the max. dimensions:
(L x W x H) 808 x 908 x 598 mm / 31.8" x
35.7" x 23.5"
GSP 25° H
IP rating IP33

Bizerba GSP H Specifications

General

Type	Slicer
Blade Diameter	330 mm
Cutting Thickness	0 - 24 mm
Material	Anodized aluminum
Operation	Manual
Voltage	230 V
Frequency	50 Hz
Protection Class	IP33
