Instruction manual GSP Machine and operating elements
38107010002 en-US 37 / 92
Fig.29: Product clamping GSP HD
5.7 Lifting device
The lifting device enables easy cleaning under the machine.
The effort and strength required for lifting and lowering the machine is
about 6kg.
CAUTION
When lowering!
Risk of crushing.
– Effort and strength required.
Move carriage away from operator side
until it comes to a stop.
Slightly lift machine up from the front us-
ing the knob and push the lifting device
backwards as far as possible using the
handle.
The area underneath the machine is now
easy to clean.
Hold the machine via the thickness knob
and pull the lifting device back into its ini-
tial position.
Fig.30: Lifting device GSP H
