Machine and operating elements Instruction manual GSP
36 / 92 38107010002 en-US
Fig.26: GSP HD, example
5.6 Product fixation device / product guide
The product fixation device or product guide prevent the product from deflecting or tilting dur-
ing slicing.
The product guide is irreversibly self-locking
on its shaft and is moveable across the full
width of the carriage. This way, it can be po-
sitioned on any product dimension.
Fig.27: Product guide
The product fixation device is irreversibly
self-locking on its shaft and is moveable
across the full width of the carriage. This
way, it can be positioned on any product di-
mension.
Fig.28: Product clamping GSP H
