Bizerba GSP H - Dimensions GSP H W

Technical data Instruction manual GSP
80 / 92 38107010002 en-US
9.4 Dimensions GSP H W
Fig.113: GSP H W 25° H
Dimensions Notes
Installation area (L x W) 532 x 478 mm / 20.9" x 18.8"
Maximum dimensions
(L x W x H)
806 mm x 911 mm x 627
mm / 31.7" x 35.9" x 24.7"
GSP 25° L
The work area of the ma-
chine includes the area
within the max. dimensions:
(L x W x H) GSP 25° H
IP rating IP33
Product size Height: 160 mm / 6.3"
Width: 290 mm / 11.4"
Round: Ø 228 mm / 9.0"
GSP 25° L
Height: 126 mm / 5.0"
Width: 290 mm / 11.4"
Round: Ø 202 mm / 8.0"
GSP 25° H
Depositing height 62 mm
95 mm
GSP 25° L
GSP 25° H
Slice thickness 0 - 24 mm / 0 - 0.9"
0 - 3 mm / 0 - 0.1"
Infinitely adjustable
Fine adjustment
Blade diameter 330 mm / 13.0"
