Bizerba GSP H - Dimensions of GSP HD with Carriage Inclination 25

Technical data Instruction manual GSP
84 / 92 38107010002 en-US
Dimensions Notes
Weight Approx. 50 kg / 110.2 lb
approx. 57 kg / 125.7 Ib with packaging
Types of current, voltages,
power consumption
See identification plate
9.7 Dimensions of GSP HD with carriage inclination 25°
Fig.116: GSP HD 25° L
Dimensions Notes
Installation area (L x W) 532 x 444 mm / 20.9" x 17.5"
Maximum dimensions
(L x W x H)
809 x 906 x 606 mm / 31.9" x
35.7" x 23.9"
GSP 25° L
The work area of the ma-
chine includes the area
within the max. dimensions:
(L x W x H) 808 x 908 x 630 mm / 31.8" x
35.7" x 24.8"
GSP 25° H
IP rating IP33
Product size Height: 160 mm / 6.3"
Width: 290 mm / 11.4"
Round: Ø 228 mm / 9.0"
GSP 25° L
Height: 126 mm / 5.0"
Width: 290 mm / 11.4"
Round: Ø 202 mm / 8.0"
GSP 25° H
