Bizerba GSP H User Manual

Instruction manual GSP Technical data
38107010002 en-US 83 / 92
Fig.115: GSP HD 18° L
Dimensions Notes
Installation area (L x W) 532 x 444 mm / 20.9" x 17.5"
Maximum dimensions
(L x W x H)
801 x 776 x 601mm / 31.5" x
30.6" x 23.7"
The work area of the ma-
chine includes the area
within the max. dimensions:
IP rating IP33
Product size Height: 188 mm / 7.4"
Width: 290 mm / 11.4"
Round: Ø 235 mm / 9.3"
Depositing height 62 mm
Slicing performance 35 - 90 slices per minute
Slice thickness 0 - 24 mm / 0 - 0.9"
0 - 3 mm / 0 - 0.1"
Infinitely adjustable
Fine adjustment
Blade diameter 330 mm / 13.0"
Blade speed 255 rpm
Blade position 40° angle
Carriage angle 18°
Dimensions packaging
(L x W x H)
820 x 700 x 823 mm / 32.3" x
27.6" x 32.4"

Bizerba GSP H Specifications

General

Type	Slicer
Blade Diameter	330 mm
Cutting Thickness	0 - 24 mm
Material	Anodized aluminum
Operation	Manual
Voltage	230 V
Frequency	50 Hz
Protection Class	IP33
