Operation Instruction manual GSP
40 / 92 38107010002 en-US
Place product on carriage rear wall and
move to gauge plate.
Position the product fixation device or
product guide against the product.
Turn in product holder and position on
the product.
Switch on machine .
Set slice thickness at knob.
Fig.34: Load the product
Using the handle, move carriage uni-
formly forth and back.
Slices drop on depositing area or are
manually removed from deflector.
If necessary, re-clamp product holder.
Once the slicing process is completed
set slice thickness to "0".
Switch off machine.
Fig.35: Slice product
Extra care must be taken due to additional risk of injury if product holder is
not used and positioned underneath the carriage.
6.1.2 Slicing product ends
The product holder is force-guided in an area of < 60mm to the blade and
cannot be swiveled up.
As soon as product ends fit between gauge plate and remnant holder, proceed as follows:
Move carriage towards operator.
Use the handle to pull the product holder
outwards and swivel it up.
Fig.36: Preparation of machine
