Machine and operating elements
Instruction manual NSF VSI / VSI W / VSI T / VSI
TW
34 / 101 38065447002 en-US
Depositing type Shingling lengthwise
Depositing type Circular pattern
Depositing type Shaving
Depositing offset crosswise
Specifies the start point for crosswise depositing.
Depositing offset lengthwise
Specifies the start point for lengthwise depositing.
Number of slices
Specifies the number of slices per portion.
Slice thickness
The slice thickness equals the thickness of the product slice.
Product feed offset
Current slice thickness is changed by this value.
Shingling distance, shingling lengthwise
The distance between slices within a shingle.
Shingling distance, shingling crosswise
The distance between slices within a shingle.
Number of layers
Specifies the number of shingles in layers on top of each other.
Shingling length, shingling crosswise
Specifies the length of the entire shingle.
Shingling length, shingling lengthwise
Specifies the length of the entire shingle.
Number of layers circular pattern
Specifies the number of repetitions of depositing pattern circu-
lar pattern. The result is a stack consisting of circles.
Circular diameter
Specifies the outer circle diameter for circular pattern.
