Maintenance
Instruction manual NSF VSI / VSI W / VSI T / VSI
TW
82 / 101 38065447002 en-US
Shaving deflector
Push shaving deflector up to fit the sheet
metal in the groove of the chainframe
first, then push it away from the operator.
Tighten screw.
Fig.100: Shaving deflector
Depositing table VSI, VSI W
Insert slightly tilted depositing table
backwards in guidance and push it
downwards.
Fig.101: Attaching the depositing table
Conveyor VSI T
Use both hands to hold on to the sides of
the conveyor belt.
Put the belt bearing down onto the take-
up pin, keeping it in a slight tilted posi-
tion.
Fig.102: Insert conveyor belt VSI T
