Handler Operation
The definition for the signal line
The Handler interface has 3 signal lines: comparison output, control output and control
input. The output signals for the BIN comparison or list sweep comparison functions are
detailed below:
Comparison Signal Lines
Comparison output signal
BIN1-BIN9
AUX
OUT
PHI (the main parameter is bigger than the high limit)
PLO (the main parameter is low)
SREJ (The test result is outside the valid range)
Control output signal
INDEX (Analog test finished signal)
EOM (Test ended and the compared data effective)
ALARM (Circuit interruption)
Control input signal
EXT.TRIG (External trigger signal)
Keylock (Key lock).
The Comparison signal distribution for the pins is described in Table 2:
Pin
Signal name
Description
1
2
3
4
5
6
7
8
9
10
11
/BIN1
/BIN2
/BIN3
/BIN4
/BIN5
/BIN6
/BIN7
/BIN8
/BIN9
/OUT
/AUX
BIN sorted result
/BIN (BIN number) output are all open collector
outputs.
12
13
/EXT.TRIG
External trigger: when the trigger mode is EXT.TRIG,
the 894/895 will be triggered by the positive-edge
pulse signal in this pin.
14
15
EXT.DCV2
External DC voltage 2:
The DC provider pin for the optoelectronic coupling
signal (/EXT_TRIG, /Key Lock, /ALARM, /INDEX, /EOM)
