BK Precision 894 User Manual

25
L2-B*
Secondary Inductance
Table 2 - Primary Parameters
*Used with transformer test fixture TL89T1.
Secondary Parameters
Parameter
Description
Q
Quality factor
D
Dissipation factor
R
s
Equivalent Series Resistance (ESR)
R
p
Equivalent Parallel Resistance
X
Reactance
B
Admittance
Θ
Phase Angle
N, 1/N*
Turn Ratio and Polarity
M*
Mutual Inductance
R2
DC Resistance
Table 3 - Secondary Parameters
*Used with transformer test fixture TL89T1.
Parameter Combinations
The combinations of primary and secondary parameters, including the series and parallel
combinations are listed below:
Primary
Parameter
Series Mode
Combinations
Parallel Mode
Combinations
C
Cs-Q
Cs-D
Cs-Rs
Cp-Q
Cp-D
Cp-Rp
Cp-G
L
Ls-Q
Ls-D
Ls-R
Lp-Q
Lp-D
Lp-Rp
Lp-G
Table 4 – Primary Parameter Combinations: Series and Parallel
Primary
Parameter
Combinations
Z
d
r
Y
d
r
