15
1. General Information
Product Overview
The B&K Precision models 894 and 895 are precision bench LCR meters. They are capable of
measuring the capacitance, inductance and resistance of components with basic accuracy
of 0.05%. These meters have an adjustable test frequency, from 20 Hz to 500 kHz (894) and
20 Hz to 1 MHz (895). With the vivid 4.3-inch TFT LCD, users can operate and read the
measurements easily. This LCR meter is designed to fit standard 19in racks with a 2U form
factor.
The sweep function provides a quick look at the characteristics of the components, allowing
the customer to systematically test the primary and secondary parameters of those
components using up to 201 frequencies. The BIN comparator function helps quickly sort
components up to 10 bins. With built-in USB, RS-232, LAN and GPIB (895 only), these LCR
meters can be remotely controlled to perform daily operations in production, quality
control and laboratory environments.
Features:
• Basic accuracy 0.05%
• Test frequency from 20 Hz to 500 KHz (894) and 1 MHz (895)
• Frequency sweep function
• Bin sorting comparator
• Adjustable measurement speed for fast readout or better accuracy
• Standard USB, Ethernet, RS-232C and GPIB interface (895 only)
• Save and recall up to 40 internal measurement setups
• 4.3” color TFT LCD display
Package Contents
Please inspect the instrument mechanically and electrically upon receiving it. Unpack all
items from the shipping carton, and check for any obvious signs of physical damage that
may have occurred during transportation. Report any damage to the shipping agent
immediately. Save the original packing carton for possible future reshipment. Every
instrument is shipped with the following contents:
1 x Model 894/895 bench LCR meter
1 x AC power cord
1 x 4-wire Kelvin clip test lead
1 x 4-terminal test fixture
1 x Certificate of Calibration
1 x Test Report
1 x Shorting Bar
