29
Press the soft key to select the secondary parameter. Then press ← to return to the
previous menu.
Note: L2A and L2B should be used with transformer test fixture TL89T1.
Test range
The measurement range should be selected in accordance with the impedance value of the
tested LCR component.
The 894/895 have 11 AC measurement ranges: 10Ω, 30Ω, 100Ω, 300Ω, 1kΩ, 3kΩ, 10kΩ,
30kΩ, 100kΩ, 300kΩ, and 1MΩ (895 only).
The 894/895 have 14 DCR measurement ranges: 30mΩ, 100mΩ, 300mΩ, 1Ω, 10Ω, 100Ω,
300Ω, 1kΩ, 3kΩ, 10kΩ, 30kΩ, 100kΩ, 300kΩ, and 1MΩ (895 only).
Setting the test range:
1) Move the cursor to the range field, the following soft keys will be displayed:
AUTO The soft key is used to set the range mode to AUTO.
HOLD The soft key is used to switch the AUTO mode to the HOLD mode. In this
mode, the range will be locked in the current measurement range, which is
displayed in the range field.
↑(+) The soft key is used to increase the range under HOLD mode.
↓(-) The soft key is used to decrease the range under HOLD mode.
2) Use the soft keys to set measurement range.
Test frequency
The frequency range of the 894 meter ranges from 20Hz to 500 KHz, and up to 1 MHz for
895.
Note: When the test function is set to DCR, the FREQ field will display “---”.
20.00 Hz, 20.01Hz ……99.99 Hz
100.0 Hz, 100.1Hz ……999.9 Hz
1.000 kHz, 1.001 kHz ……9.999 kHz
10.00 kHz, 10.01 kHz……99.99 kHz
100.0 kHz, 100.1 kHz……1 MHz
Table 6 - Frequency Range, Test Frequency Points and Resolution
Setting the test frequency:
There are two ways to set measurement frequency: soft keys, numeric keys.
1) Move the cursor to the FREQ field, and the following soft keys will be displayed:
