Clear Table
This option clears the table completely.
Mode
The meter can automatically sweep up to 201 frequencies, test levels or DC bias. Two
sweep modes are available: SEQ and STEP. In SEQ mode, each press of the TRIGGER button
will initiate a test of all list sweep test points. In STEP mode, each press of the TRIGGER
button test one point at a time of the list sweep.
NOTE: When the trigger mode is set to INT, sweep test modes of SEQ and STEP will not be controlled by
[TRIGGER]. When the trigger mode is set to MAN, [TRIGGER] can be used to trigger the list sweep
test.
Setting the List Sweep Mode:
1) On the <LIST SWEEP DISP> page, move the cursor to MODE, and the following soft
keys will be displayed:
 SEQ
 STEP
2) Press SEQ to set the sweep mode as sequential sweep test mode.
3) Press STEP to set the sweep mode as single step sweep test mode.
Sweep Parameter
The sweep parameters can be: frequency [Hz], level [V], level [I], bias [V], and bias [I].
Setting the Measurement parameter
1) Press [SETUP] and then LIST SWEEP to enter into the <LIST SWEEP SETUP> menu.
2) Move the cursor the line following MODE. The following soft keys will be displayed:
 FREQ [Hz] = Frequency as the sweep parameter.
 LEVEL [V] = Voltage as the sweep parameter.
 LEVEL [A] = Current as the sweep parameter.
 BIAS [V] = DC bias voltage as the sweep parameter.
 BIAS [A] = DC bias current as the sweep parameter.
3) Press one of above soft keys to select the list sweep parameter.
Sweep Test Points
Setting the Sweep Test Points
1) Press [SETUP] and then LIST SETUP to enter into the <LIST SWEEP SETUP> menu.
2) Using the cursor keys, move the cursors to a sweep point. The following options will
become available:
2
3
