List Sweep Setup
The List Sweep Setup page allows the user to configure the List Sweep for up to 201
frequencies, test signal levels, DC bias voltage or DC current source.
On <LIST SWEEP SETUP> page, the following list sweep parameters can be set.
 Mode (SEQ or STEP)
 Sweep Parameters (frequency [Hz], level [V], level [A], bias [V], bias [A])
 Sweep Test Points (Hz, V, A)
 Limit Parameter (LMT)
 High/Low Limit (HIGH, LOW)
 Delay in Seconds (DELY)Clear Table (No.)
Figure 23 - List Sweep Setup
No.
When the cursor is set in this area, the soft keys will display “PREV PAGE” and “NEXT PAGE”.
By pressing any of these two soft keys the user will be able to navigate through the List
Sweep Display.
1
3
4
5
6
2
1
