56
3) Using the arrow keys, move the cursor to AUX, the following soft keys will be
displayed.
ON
OFF
4) Press the ON softkey to enable the Aux Bin or, press OFF to turn the Aux Bin off.
Comparator Function (COMP)
Nine bin limits of the primary parameters and one bin limit of the secondary parameters can be
set. The tested results can be sorted into ten bins (BIN 1 to BIN 9 and BIN OUT). This function is
especially useful if the handler interface is used.
Enabling Compare Function
1) Press SETUP.
2) Press LIMIT TABLE to enter into the <LIMIT TABLE SETUP> page.
3) Move the cursor to COMP, the following soft keys will be displayed.
ON
OFF
4) Use above soft keys to enable (ON) or disable (OFF) the compare function.
High/Low Limits
The meter can set bin limits of nine primary parameters and one secondary parameter. The test
results can be sorted into ten bins at most (BIN 1 to BIN 9 and BIN OUT). The high/low limits of
primary parameters can be set in high limit and low limit of bins from BIN 1 to BIN 9. The limit
of the secondary parameter can be set in the HIGH and LOW fields at the bottom of the screen
in the field labeled “2
nd
” (2
nd
for Secondary Parameter) at the bottom of the Limit Table SETUP
screen, as detailed in Figure 19.
Operation steps for setting high/low limit
Follow this steps to set sorting limits:
1) Press SETUP.
2) Press LIMIT TABLE to enter into the <LIMIT TABLE SETUP> page
3) The primary parameter must be set in the <MEAS DISPLAY> page. Access this page by
pressing the MEAS key and follow the instructions detailed in the section: Selecting
