Press the MEASURE SHORT soft key. Full frequency correction takes approximately 75 seconds.
The following soft key will be displayed on the top right corner of the display:
ABORT: This soft key cancels the current short correction operation.
DCR SHORT: Short resistance test for DCR.
The following soft key will be displayed on the top right corner of the display:
ABORT: This soft key cancels the current short correction operation.
4) Insert the short plate to the test fixture.
5) Move the cursor to the SHORT zone. ON, OFF and MEAS SHORT will be displayed
in the soft key zone.
6) Press MEAS SHORT to execute the short calibration. The meter will beep when the
correction is completed
7) Press ON to turn the short calibration function.
8) Move the cursor to the LOAD zone. ON, OFF will be displayed in the soft key zone.
9) Press OFF to turn off the load calibration function.
10) Move the cursor to the FREQ zone, ON, OFF, MEAS OPEN, MEAS SHORT and
MEAS LOAD will be displayed in the soft key zone.
11) Press OFF to turn off the point-frequency calibration function of FREQ.
Load Correction (Point-Frequency Correction)
The Load Correction performs a correction at frequency points defined by the user (up to 201
frequencies). The preset frequencies can be set in the FREQ field of the display. The standard
reference values can be set in the setup zones of REF A and REF B.
The reference values of the component must be entered prior to performing a Load Correction.
