Talk Only
The Talk only function configures the instrument to send each measurement result to bus
through the remote interfaces. When it is ON, the instrument cannot be controlled by a remote
PC.
1) Move the cursor to TALK ONLY, the following soft keys will be displayed.
ON
OFF
2) Press ON to turn on the talk only function or OFF to turn off this function.
Bias SRC
Bias source is used to select the DC bias power. The instrument provides the bias source as
shown below:
INT mode
The standard DC bias voltage source is from -5 V to +5 V and the DC bias current source is
from -50 mA to +50mA.
Baud Rate
Baud rate is used select the baud rate for the RS-232 or USBCDC (virtual COM) interface.
Move the cursor to BAUD RATE, and the following soft keys will be displayed.
↑(+)
This soft key is used to increase the baud rate.
↓(-)
This soft key is used to decrease the baud rate.
The available baud rates are: 9600, 19200, 28800, 38400, 48000, 57600, and 115200.
Date/Time
The date format is: Year, Month, and Day.
The time format is 24 hrs. For example: 16:00:00 hrs. would be used instead of 4:00:00 pm.
