Front Panel Overview
Figure 2 - Front Panel Overview
Front Panel Description
Power On/Off Switch
Log Key
Cursor
Ground Terminal
Measurement Terminals
Trigger Key
Reset Key
Pass/Fail LED indicators
Numerical Keypad
Menu Keys: MEAS, SETUP and SYSTEM
Softkeys
Copy Key
4.3” TFT Color LCD Display Window
USB Host Port
Auxiliary Keys
Zoom Button
1
4
13
7
8
9
14
11
10
15
2
5
12
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
