55
value can be set, but it is optional.
Setting the Nominal Value
1) Press SETUP.
2) Press LIMIT TABLE to enter into the <LIMIT TABLE SETUP> page.
3) Move the cursor to NOM.
4) Use numeric keys to input nominal value.
The following softkeys for the units of the nominal value will become available:
p, n, µ, and m
Press the → key to access additional units softkeys:
k, M, *1
Alternatively, enter a value directly using the numeric keypad, then press ENTER.
Auxiliary Bin (AUX)
Three conditions may occur during the secondary parameter sorting that will determine if the
Auxiliary Bin would be enabled:
On <LIMIT TABLE SETUP> page, no low/high limits of the secondary parameters have
been set.
On <LIMIT TABLE SETUP> page, the low/high limits of the secondary parameters have
been set but Aux function is set as OFF.
In this case, only those components that have a secondary parameter that is within the
specified limits will be sorted. If the secondary parameters are outside the limits set
and the corresponding primary parameters are within limit ranges, the components will
be sorted into BIN OUT.
On <LIMIT TABLE SETUP> page, the low/high limits of the secondary parameters have
been set and the Aux function is set as ON.
In this case, if the primary parameter is out of the limit range, it is sorted into BIN OUT.
If the primary parameter of DUT is within the limit range but its secondary parameter is
out of the limit range, the DUT will be sorted into the Aux bin.
Note: When the secondary parameter has the Low Limit set only, with the auxiliary bin set to ON, if the
primary parameter of the DUT is within the limit range and the secondary parameter is smaller than or
equal to its low limit, the DUT will be sorted into the auxiliary bin. When the secondary parameter has
the high limit set only, with the auxiliary bin set to ON, if the primary parameter of DUT is within the
limit range and the secondary parameter is larger than or equal to its high limit, the DUT will be sorted
into the auxiliary bin.
Setting the Auxiliary Bin
1) Press the SETUP key. (Located between the MEAS and SYSTEM keys).
2) Press the LIMIT TABLE softkey.
