66
List Sweep Display Fields
No.
When the cursor is set in this area, the soft keys will display “PREV PAGE” and “NEXT PAGE”.
By pressing any of these two soft keys the user will be able to navigate through the List Sweep
Display.
FREQ (Hz)
This shows the swept frequencies.
R[:] X[:]
This displays the primary and secondary parameter measurements.
CMP (Compare)
This indicates the compare results of the swept points. L means the result is lower than the limit
and H is higher than the limit. A blank space indicates that it is within the limit.
Operation steps for setting the list sweep mode:
To set the sweep mode on the <LIST SWEEP DISP> page as SEQ or STEP:
1. On the < LIST SWEEP DISP > page, move the cursor to MODE, and the following
softkeys will be displayed:
SEQ
STEP
2. Press SEQ to set the sweep mode as sequential sweep test mode
Or
Press STEP to set the sweep mode as single step sweep test mode.
