BK Precision 894 User Manual

83
Resolution
0. 1 µA
*Auto Level Control
1: Resolution and impedance see AC source (ALC OFF) specification
Measurements
Measurement
parameters
L, C, R, G, X, Z, Y, B, θ, Q, D, DCR
Transformer measurement
parameters
2
L2A, L2B, N, 1/N, M
Basic accuracy
0.05 %
AC source Output impedance
(± 2%)
30 Ω, 50 Ω, 100 Ω
Typical
measurement time
(≥10 kHz)
(excluding display
refresh time)
Fast
13 ms / measurement
Medium
67 ms / measurement
Slow
187 ms / measurement
Equivalent circuit
Series, Parallel
Range mode
Auto, Hold
Averaging
1-255 measurements
Correction function
Open, Short and Load correction
Cable length compensation
0, 1, & 2 meters
Math operations
Direct reading, ∆ABS, ∆%
Trigger mode
Internal, Manual, External, Bus
Delay time setup
Time from trigger to start: 0 to 60 seconds
Resolution: 1 ms
Comparator (Bin sorting)
10-bin sorting, primary bins BIN1-BIN9 and OUT, secondary bin AUX
Bin counter: 0 to 999,999
PASS/FAIL indication via front panel LED or handler interface signal
List
sweep
201 sweep points
Sweep test frequency, test signal AC voltage, test signal AC current,
test signal DC bias voltage and test signal DC bias current
Measurement
parameters
Primary and secondary
Sweep modes
Linear or Logarithmic
Trigger mode
Sequential and Step
Comparator
One pair of lower and upper limits for primary or secondary
parameter (user selectable)
Internal non-volatile memory
Save / recall 40 setups
2: Requires optional fixture TL89T1
