Group ID Parameter Type Index Minimum Maximum Interpretation
Display
4.0 Brightness fixed16 – 0 1
0.0 = minimum,
1.0 = maximum
4.1 Overlay enables
int16
bit field
– – – 0x4 = zebra
– – – 0x8 = peaking
– – –
4.2 Zebra level fixed16 – 0 1
0.0 = minimum,
1.0 = maximum
4.3 Peaking level fixed16 – 0 1
0.0 = minimum,
1.0 = maximum
4.4
Color bars display
time (seconds)
int8 – 0 30
0 = disable bars, 1-30 =
enable bars with timeout (s)
4.5 Focus Assist int8
[0] = focus
assist method
– –
0 = Peak,
1 = Colored lines
[1] = focus
line color
– –
0 = Red,
1 = Green,
2 = Blue,
3 = White,
4 = Black
Tally
5.0 Tally brightness fixed16 – 0 1
Sets the tally front and tally
rear brightness to the
same level.
0.0 = minimum,
1.0 = maximum
5.1 Front tally brightness fixed16 – 0 1
Sets the tally front
brightness.
0.0 = minimum,
1.0 = maximum
5.2 Rear tally brightness fixed16 – 0 1
Sets the tally rear brightness.
0.0 = minimum,
1.0 = maximum
Tally rear brightness cannot
be turned off
Reference
6.0 Source int8 enum – 0 2
0 = internal,
1 = program,
2 = external
6.1 Offset int32 – – – +/- offset in pixels
Confi-
guration
7.0 Real Time Clock int32
[0] time _ _ BCD - HHMMSSFF (UCT)
[1] date _ _ BCD - YYYYMMDD
7.1 System language string _ _ _
ISO-639-1 two character
language code
7.2 Timezone int32 _ _ _ Minutes offset from UTC
7.3 Location int64
[0] latitude _ _
BCD - s0DDdddddddddddd
where s is the sign:
0 = north (+), 1 = south (-);
DD degrees, dddddddddddd
decimal degrees
[1] longitude _ _
BCD - sDDDdddddddddddd
where s is the sign: 0 = west
(-), 1 = east (+); DDD degrees,
dddddddddddd
decimal degrees
269Developer Information
