Bit 4/rfg enable
Rfg enable = 0 the reference speed comes from a manufacturer-specific special func-
tion.
Rfg enable = 1 The reference speed corresponds to the ramp output.
The special function is evaluated only if 1299 S. Special Function Generator ≠ “9-
Zero”.
If 1299 S. Special Function Generator = “9-
Zero”, the value of the ramp output will
always be used.
Bit 5/rfg unlock
Rfg unlock = 0 The last speed will be maintained and used.
Rfg unlock = 1 The ramp function is active and changes according to the reference
value and the ramp.
Bit 6/rfg use ref
Rfg use ref = 0 Reference value “0” is used.
Rfg use ref = 1 The reference value from
Target Velocity is used.
Bit 8 Halt
STOP = 0  Execute positioning.
STOP = 1  Stop axis. (The frequency inverter remains enabled in “Operation
enabled” state.)
If special function generator 1299 S. Special Function Generator ≠ “9-Zero”, the
reference value from the ramp output will also be used if bit 4 “rfg enable” = 1, and if
bit 4 “rfg enable” = 0, the reference value from the source specified in 1299
S. Spe-
cial Function Generator will be used.
Reference value source
1299 Q. Special Function Genera-
tor ≠ “9-Zero”
1299 Q. Special Function Genera-
tor = “9-Zero”
Bit 4 rfg enable = 0
Reference value from special func-
tion
Reference value from ramp output
Bit 4 rfg enable = 1
Reference value from ramp output
