DS7200V2-EXP | Installation Guide | 1. Introduction
EN | 10
Bosch Security Systems, Inc. | 04/12 | F01U253045-02
1.7.3 RF Devices
• RF3227E RF Receiver: Supervises the use of
wireless devices. Up to 2 allowed per system.
• RF3332E RF Keyfob: 2-button keyfob that
can arm/disarm the system and create a
Panic event if programmed.
• RF3334E RF Keyfob: 4-button keyfob that
can arm/disarm the system and create a
Panic event if programmed. It can also
control other devices.
• RF3401E Point Transmitter: Point
transmitter that features a supervised sensor
loop and a magnetic reed switch. External
magnet assembly allows for quick and easy
installation on doors and windows.
• RF3405E Inertia Transmitter: Magnetic and
dry contact wireless transmitter with a built-
in inertia sensor used for monitoring doors,
windows, or other dry contact devices.
• RF3503E Two-Button Transmitter:
Wireless, two-button transmitter that sends a
medical or panic alarm signal to the
monitoring system.
• RF1100E Glassbreak Detector: Wireless
transmitter used for detecting breaking glass.
• RF280ETHS Wireless Smoke Detector:
Wireless photoelectric smoke detector with
built-in 135°F (57°C) heat sensor and 85 dB
sounder.
• RF835E Wireless TriTech PIR/Microwave
Detector: Wireless detector that utilizes
passive infrared (PIR) technology, microwave
(MW) technology, and artificial intelligence to
detect motion.
• RF940E Wireless PIR Detector: High
performance PIR motion sensor.
1.7.4 Programming Tools
• DS7447E/DS7447V2 Text Keypad: Required
for keypad programming.
• PK32 Program Key: Copy system
programming entries to key for quick delivery
to another system. Can also be used as a
backup disk.
• Remote Programming Software (RPS):
Remote programming and diagnostic tool.
1.8 System Batteries
1.8.1 Standby Battery
12 V, 7 Ah or 18 Ah sealed lead-acid rechargeable
battery
• Power Sonic: PS-1270; PS-12180
• YUASA: NP7-12; NPG18-12
1.8.2 RAM Backup Battery
• 3 V coin-type lithium battery (Panasonic
CR2032 or equivalent)
1.9 Available Power
1.9.1 Auxiliary Power
Use auxiliary power terminals to power devices
requiring continuous power. Up to 1.2 A is
available for continuously powered devices.
1.9.2 Alarm Power
The Alarm Power (ALRM +) terminal provides
positive 12 VDC for Programmable Output 2 (PO
2) when it is configured as a siren driver and PO
1 when it is configured as the alarm output. Up to
1.85 A of alarm power is available.
1.10 Installer Keypad/RPS Connector
Use the Aux/Data connector to connect an
Installer Keypad or a DX4010i/DX4010 to the
control panel for programming and diagnostics.
