DS7200V2-EXP | Installation Guide | 4. Reference Materials
EN | 130
Bosch Security Systems, Inc. | 04/12 | F01U253045-02
Table 51: Terminal Descriptions
1,2 18 VAC 18 V, 50 VA; from transformer.
3 Earth Ground Symbol Earth ground.
4 Data, Grn (Green) Data Bus data on Terminal 4. Control panel supports up to 305 m (1000 ft) of 0.8 mm
(#22 AWG) wire on these terminals (any configuration).
5 Data, Yel (Yellow) Data Bus data on Terminal 5. Control panel supports up to 305 m (1000 ft) of 0.8 mm
(#22 AWG) wire on these terminals (any configuration).
6,7 Aux Power 12 VDC (-) Terminals 6 and 7 are auxiliary power. 1.2 A. Include any programmable outputs (PO 1
to PO 4) not configured for alarm output. Self-resetting overcurrent protection.
8,9 Aux Power 12 VDC (+) Terminals 8 and 9 are auxiliary power. 1.2 A. Include any programmable outputs (PO 1
to PO 4) not configured for alarm output. Self-resetting overcurrent protection.
Aux/Data (RYGB) 4-pin connector to Data Bus and auxiliary power. Use to connect an Installer Keypad for
keypad programming.
Batt + Battery (+) spade. (red wire)
Batt - Battery (-) spade. (black wire)
10 PO 4 Programmable Output 4, up to 500 mA (-). Include in Aux Power calculations for all
except “Alarm” output functions. Self-resetting overcurrent protection.
11 PO 3 Programmable Output 3, up to 500 mA (-). Include in Aux Power calculations for all
except “Alarm” output functions. Self-resetting overcurrent protection.
12 PO 2 Programmable Output 2. 500 mA (-).Include in Aux Power calculations for all except
“Alarm” output functions. Supervised for Horn/Speaker alarm function. Self-resetting
overcurrent protection.
13 ALRM + Alarm power. Up to 1850 mA. Self-resetting overcurrent protection. Provides power for
supervised siren driver (PO 2) and Alarm Output (PO 1, A).
14 PO 1, A Jumper sets PO 1 terminals A (14) and B (15) for “dry” Form “A” contact or for Alarm
Output (using PO 1, A as negative (-) terminal).
15 PO 1, B Jumper sets PO 1 terminals A (14) and B (15) for “dry” Form “A” contact or for Alarm
Output (using PO 1, A as negative (-) terminal).
16 SMK + Not used.
17 L-1 Sensor Loop 1. Wire length for Sensor Loops 1 to 8 are limited only by the resistance
on the loop and potential EMI problems. Resistance must be < 100 with EOL resistor
shorted and detection devices connected.
18 Com Common for Sensor Loops 1 and 2.
19 L-2 Sensor Loop 2 input.
20 L-3 Sensor Loop 3.
21 Com Common for Sensor Loops 3 and 4.
22 L-4 Sensor Loop 4.
24 Com Common for Sensor Loops 5 and 6.
25 L-6 Sensor Loop 6.
26 L-7 Sensor Loop 7.
27 Com Common for Sensor Loops 7 and 8.
28 L-8 Sensor Loop 8.
29 T Connections for incoming phone line.
30 T1 Connections for premises devices such as telephones.
31 R1 Connections for premises devices such as telephones.
32 R Connections for incoming phone line.
PO 1 SELECT Configures PO 1 for Form “A” relay or Alarm Output.
Auxiliary Auxiliary Module and/or Program Key (PK32) 8-pin connector.
