DS7200V2-EXP | Installation Guide | 1. Introduction
EN | 7
Bosch Security Systems, Inc. | 04/12 | F01U253045-02
1. Introduction
1.1 Documentation Conventions
1.1.1 Type Styles Used
To help identify important items in the text, the
following type styles are used:
Bold text Indicates important text or terms
that you should note.
Italicized text Refers you to a drawing, table, or
other section of this document.
[#][9][1] Bracketed numbers represent
keypad keys. When next to one
another, they represent the key
sequence to press for a particular
function. For this example, pressing
[#] followed by [9] and [1] begins
the keypad test function.
1|6
Numbers separated by a vertical bar
represent output function types.
This example is for Output Function
Type 1|6:
Strobe.
1.1.2 Notes, Cautions, and Warnings
Throughout this document there are important
notes that address personal and/or equipment
safety issues, system operation issues, etc. They
are set off as follows:
The Important Note identifies
information intended for successful
operation.
The Caution Note identifies
information intended to prevent an
incident that could prohibit the
functionality of the
program/equipment.
The Warning Note identifies
information intended to prevent an
incident that could prohibit the
functionality of the
program/equipment and/or personal
injury.
The No Static Note identifies
components that are static-sensitive.
Follow anti-static procedures when
handling these components.
1.1.3 Other Conventions
Programming parameter titles are identified as
follows:
Programming Parameter Title
1.2 Scope of Document
See below for an overview of this document and
other documents related to the
DS7240V2/DS7220V2 Control Panels:
Table 1: Document Overview
User’s Guide 4998153894 Contains keypad
operation instructions
for the end-user.
Covers use of the LCD
(text) keypad and the
LED keypad.
Installer’s
Guide (this
document)
4998153893 Contains all wiring and
setup instructions,
and basic
programming
parameters with
descriptions.
Troubleshooting
information also
Expert
Programmin
g Guide
4998153891 Contains all
programming
parameters with
descriptions and
keypad programming
instructions.
Release
Notes
4998153890 Contains issues with
control panel that
were found after
printing of the
documentation.
System
Worksheet
4998153887 Contains all
programming
parameter defaults
and space to record
any default changes
made during setup of
the control panel.
