144 en | Technical Data Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
LSN elements Max. number
Stand-alone panel 4096
Per network panel 2048
Total network 32768
NAC groups Max. number
NAC groups with more than one FNM-420, per loop 6
Praesideo/PAVIRO Max. number
In CAN network, per panel 1
In Ethernet network, per panel 1
Triggers (each trigger counts as one sounder group) 244
Per fire panel Max. number
Sets, e.g. bypass group 192
Functional modules 46
Printer 4
Alarm counters (external, internal, testing) 3
Entries in the event database 10000
FSP-5000-RPS configuration interfaces (USB, COM) 2
Maximum number of outputs (sounders, controls, etc.) activated in
parallel due to the same event
508
Configuration limits per fire panel (FSP-5000-RPS) Max. number
Timer channels 20
Time control programs 19
Configuration for a Specific Day 365
Permission levels 4
User profiles 200
Sum counters and counters (in total) 60000
Exportable objects including counters in the entire panel cluster
(without pre-defined system counters)
2000
Importable objects including counters (without pre-defined system
counters)
2000
Automatic connections to FMR-5000-C 3
Blocks of State-Dependent Rules (depending on what kind of
activations are possible)
8
Maximum number of rules within a block 254
