Bosch FPA-5000 System Information Guide

146 en | Technical Data Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
Component Power loss
PRS-0002-C 0.07W
RMH 0002 A 1.16W
RML 0008 A 1.04W (all relays activated)
UPS 2416 A 28.00W
7.3 Housing and Accessories
7.3.1 Housings for Frame Installation
Housing material Sheet steel, painted
Housing color Slate gray, RAL7015; front: anthracite gray, RAL7016
Housing type Dimensions (HxWxD) Dimensions including mounting
frame
Weight
CPH 0006 A approx. 638 x 440 x 145mm approx. 663 x 455.5 x 236mm 12.5kg
MPH 0010 A approx. 638 x 440 x 145mm approx. 663 x 455.5 x 236mm 12.5kg
EPH 0012 A approx. 638 x 440 x 145mm approx. 663 x 455.5 x 236mm 13.2kg
PMF 0004 A approx. 502 x 440 x 145mm approx. 527 x 455.5 x 236mm 11.4kg
PSF 0002 A approx. 267 x 440 x 145mm approx. 292 x 455.5 x 236mm 6.4kg
USF 0000 A approx. 267 x 440 x 145mm approx. 292 x 455.5 x 236mm 6.4kg
7.3.2 Housings for Wall Mounting
Housing material Sheet steel, painted
Housing color Slate gray, RAL7015; front: anthracite gray, RAL7016
Housing type Dimensions (HxWxD) Weight
HCP 0006 A approx. 638 x 440 x 149mm 12.5kg
HBC 0010 A approx. 840 x 440 x 149mm 17.0kg
HBE 0012 A approx. 840 x 440 x 149mm 17.0kg
PSB 0004 A approx. 502 x 440 x 149mm 11.4kg
PSS 0002 A approx. 267 x 440 x 149mm 6.4kg
DIB 0000 A approx. 267 x 440 x 149mm 6.4kg
7.3.3 PRS-0002-C Panel Rail Short for 2 Modules
Input voltage 24VDC (20VDC to 30VDC)
Current consumption at 24 V
DC
2.8 mA
Output voltage 5VDC ± 4.5 %/24 V DC
Maximum input current 8 A at 24VDC

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
