156 en | Technical Data Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
7.5.13 RML 0008 A Relay Module for Low Voltage
Input voltage 20VDC to 30VDC/5VDC ± 5%
Maximum current consumption
– Standby operation 4mA
– All relays tripped 68mA
Maximum contact load 1A at 30VDC resistive
Space required (H x W x D) approx. 127 x 96 x 60mm
Weight approx. 150g
Installation of the power supply unit is described in RML 0008 A Relay Module for Low Voltage,
page 118.
7.6 FPP‑5000 External Power Supply Unit Kit 24V/6A
7.6.1 FPP‑5000 Kit
Input voltage range 100VAC to 240VAC
Input frequency range 50Hz to 60Hz
Efficiency > 85%
Back-up time >100ms at 230VAC
Output voltage
– With mains supply 26 - 29VDC (depending on temperature),
26.8VDC nominal (at 40°C)
– With battery supply 21 - 23VDC
Maximum output current 6A
Max. output 160W (permanent)
Maximum load of fault outputs BATFAULT,
ACFAULT, and collective fault
0V/0 - 20mA
2 voltage outputs, switchable +24V/2.8A (20.4-30V), battery buffered
Housing material Sheet steel, painted
Housing color Slate gray, RAL7015
Front: anthracite gray, RAL7016
Dimensions, installed (H x W x D) approx. 527 x 456 x 326mm
Protection class as per EN 60950 Class I equipment
Permissible operating temperature -5°C to 50°C
Permissible storage temperature -20°C to 60°C
Relative humidity Max. 95% non-condensing
Cooling Ventilation without ventilator
