18 en | Product Description Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
Housing type Front door, lock left side Front door, lock right side
HCP 0006 A FDT 0003 A FDT 0000 A
HBC 0010 A FDT 0002 A FDT 0001 A
HBE 0012 A FDT 0002 A FDT 0001 A
The technical data for the housings can be found in Housings for Wall Mounting, page 146.
2.6 System Overview of FPA-5000 with Peripherals
The following figure shows a typical fire detection system design using an FPA-5000 Fire
Panel.
EOL
LSN improved/classic
1
2
Figure2.7: System overview of FPA-5000 with peripherals
Position Description
1 LSN loop (classic or improved version)
