Modular Fire Panel Technical Data | en 151
Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089
for switch outputs Max. 5.6A (2x 2.8A cannot be connected in
parallel)
Maximum load of fault outputs BAT
FAULT, AC FAULT and collective fault
0V/0 - 20mA
Maximum battery resistance (fault
threshold)
430mΩ
Voltage outputs
2 switchable outputs +24V (20.4 - 30V), 2.8A, battery buffered
(programmable)
Display and operating elements
1 green LED Mains power on
3 yellow LEDs Mains fault /fault in battery1/fault in battery2
1 button LED test, start charging manually, reset switch
outputs
Space required (H x W x D) approx. 127 x 96 x 60mm
Weight 193g
Permissible operating temperature -5°C to 50°C
Permissible storage temperature -25°C to 85°C
Installation of the power supply unit is described in BCM‑0000‑B Battery Controller Module,
page 101.
7.5.3 CZM0004A 4Zone Conventional Module
Input voltage 20VDC to 30VDC
5VDC ± 5%
Maximum current consumption
Standby mode (all 4zones) 65mA (at 24VDC)
In case of alarm (all 4zones) 65mA + 100mA per zone (at 24VDC)
Outputs (OUT1-OUT4)
Maximum output voltage 20VDC ± 5%
Maximum output current 100mA ± 10% per zone
Max. line resistance 2 x 25Ω per zone
Auxiliary power supply (AUX1-AUX4)
Max. output current (total of all 4
outputs)
230mA
Space required (H x W x D) approx. 127 x 96 x 60mm
Weight without packaging Approx. 135g
Operating and display elements 8LEDs (4x red, alarm/4x yellow, fault)
4keys (LED test)
