150 en | Technical Data Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
7.4.3 FSP-5000-RPS Programming Software
The following minimum system requirements are defined for the FSP-5000-RPS Programming
Software:
– Operating system: Windows 7 (32bit or 64bit), Windows 10 (32bit or 64bit).
– Hard disk: At least 1GB storage capacity.
– RAM: At least 500MB.
7.5 Functional Modules
The functional modules have the following technical specifications in common:
Permissible operating temperature -5°C to 50°C
Permissible storage temperature -20°C to 60°C
Relative humidity Max. 95% non-condensing
Housing material and color ABS plastic, satin finish, anthracite, RAL7016
Safety standards EN60950
Protection class IP30
Alternative technical data is listed for the individual modules.
7.5.1 ANI0016A Annunciator Module
Display elements 16 red LEDs, 16 yellow LEDs
Input voltage 20VDC to 30VDC/5VDC ± 5%
Maximum current consumption
– Standby mode (all LEDs off) 6mA
– In case of alarm (all LEDs on) 26mA
Space required (H x W x D) approx. 127 x 96 x 60mm
Weight approx. 206g
Installation of the power supply unit is described in ANI0016A Annunciator Module, page 101.
7.5.2 BCM‑0000‑B Battery Controller Module
Input voltage 20.4V to 30V
Current consumption at 23VDC
– Standby operation 25mA
– Fault 40mA
Permissible battery capacities
– with 2batteries 24to26Ah, 36to45Ah
– with 4batteries 48to52Ah, 72to90Ah
Maximum current
– of the module Max. 6A
– to panel rails Max. 6A
