Modular Fire Panel Installation | en 43
Bosch Sicherheitssysteme GmbH System Information 09.2017 | 11.3 | F.01U.028.089
Functional Modules
– Functional modules are encapsulated; the connection terminals are protected against
static discharge.
Building Management System
– If connected to a building management system (Bosch Building Integration System BIS)
via an Ethernet interface using an OPC server, the following must be noted:
In a multi-building network, it is essential to clarify with the network administrator
whether the network is designed for multi-building connections (e.g. no interference due
to differences in grounding potential).
Documentation
– All product documentation including the operating instructions can be found on the CD
that is supplied with the FPA-5000.
The current and full product documentation can also be found on
www.boschsecurity.com.
– For those with access rights, the current wiring guide can be found on the Extranet
www.boschbuildingsecurity.de/extranet . This contains information about the wiring of
the functional modules and the peripherals.
– A printed user guide in the relevant national language is supplied with the panel
controller. Store the documents in a safe place.
4.2 Quick Installation Guide
1 Keep to hand:
– The installation instructions supplied with the relevant components (housing, frame,
cables etc.) (see Installation of Housing Components, page 44).
– The required tools.
An overview of the required tools can be found in the installation instructions.
2 Preparation
– Lay the pre-cabling.
– Optional: network cabling.
3a Installation of wall mounting housing
Install:
– Housing
– Optional: accessories for housing
– Power supply bracket
– Power supply unit and batteries
– Panel rail
– Panel controller
– Functional modules
3b Installation of frame installation housing
Install:
– Mounting frames
– Housing
– Optional: accessories for housing
– Power supply unit and batteries
– Panel rail
– Panel controller
– Functional modules
