154 en | Technical Data Modular Fire Panel
09.2017 | 11.3 | F.01U.028.089 System Information Bosch Sicherheitssysteme GmbH
Cable length max. 1600m, depending on configuration and cable
type
Number of LSN elements max. 127 LSN classic elements
max. 254 LSN improved elements
LSN line current max. 300mA, depending on configuration and cable
type
Auxiliary supply AUX
(28VDC)
max. 500mA for an LSN loop (ERT technology) or 2x
max. 500mA with 2 stubs
Space required (H x W x D) approx. 127 x 96 x 60mm
Weight approx. 225g
Installation of the power supply unit is described in LSN0300A LSNimprovedModule 300mA,
page 113.
7.5.10 LSN1500A LSN improved Module 1500mA
Operating and display elements 2 LEDs (1xred, alarm/1xyellow, fault)
1 button (LED test)
Input voltage 20VDC to 30VDC/5VDC ± 5%
Output voltage
– LSN 30 ± 0.85VDC
– Auxiliary supply AUX 28 ± 1.0VDC
Maximum current consumption 4010mA at 24VDC
Nominal current consumption
– Module 260mA at 24VDC
– LSN 1.7x current consumption of the LSN elements
– AUX 1.2x auxiliary supply AUX
Cable length max. 3000m, depending on configuration and cable type
Number of LSN elements Max. 127 LSN classic elements
Max. 254 LSN improved elements
LSN line current
– Standby max. 750mA, depending on configuration and cable type
– Alarm max. 1500mA, depending on configuration and cable
type
max. 300mA when connecting LSN classic elements
Auxiliary supply AUX
(28VDC)
max. 500mA for an LSN loop (ERT technology) or 2x
max. 500mA with 2 stubs
Space required (H x W x D) approx. 127 x 190 x 60mm
Weight approx. 440g

Bosch FPA-5000 Specifications

General

Max Number of Detectors per Loop	254
Display	LCD
Network Capability	Yes
Power Supply	24 V DC
Operating Temperature	-5°C to +50°C
Communication Ports	Ethernet
Humidity Range	95% non-condensing
