SmartControl™ Meter & TouchPoint™ 37 9E-926
Operation Instructions
Table 2a: TouchPoint Connectors
Item Reference
Designation
Description Wire Color Function
1
J1, pin 1 DC Common Black DC Power
J1, pin 2 DC Common Black
J1, pin 3 +24 VDC Red
J1, pin 4 +24 VDC Red
2
J2, pin 1 PRISM-Main Shield Clear insulation PRISM-Main communication
J2, pin 2 PRISM-Main Shield Clear Insulation
J2, pin 3 PRISM-Main "A" White
J2, pin 4 PRISM-Main "A" White
J2, pin 5 PRISM-Main "B" Blue
J2, pin 6 PRISM-Main "B" Blue
3
J3, pin 1 PRISM-Sub Shield Clear Insulation PRISM-Sub communication
J3, pin 2 PRISM-Sub "A" White
J3, pin 3 PRISM-Sub "B" Blue
J3, pin 4 DC Common Black
J3, pin 5 +24 VDC Red
4
J4, pin 1 DC Common
J4, pin 2 Aux Input 1
J4, pin 3 DC Common
J4, pin 4 Aux Input 2
J4, pin 5 DC Common
J4, pin 6 Aux Input 3
J4, pin 7 QuickStart Input
J4, pin 8 +24 VDC
5
J5, pin 1 Aux Output 1 Aux Output 1
J5, pin 2 +24 VDC
J5, pin 3 Aux Output 2 Aux Output 2
J5, pin 4 +24 VDC
6
J6, pin 1 Aux Output 3 Aux Output 3
J6, pin 2 +24 VDC
J6, pin 3 Aux Output 4 Aux Output 4
J6, pin 4 +24 VDC
7
J7, pin 1 Aux Output 5 Aux Output 5 (Front for pulsator)
J7, pin 2 +24a VDC
J7, pin 3 Aux Output 6 Aux Output 6 (Rear for pulsator)
J7, pin 4 +24a VDC (Common for pulsator)
J7, pin 5 +24a VDC
J7, pin 6 +24 VDC
8
J8, pin 1 Programming Factory use only
