and 8K
GI: The guard interval. The guard interval may be 1/4, 1/8,
1/16 or 1/32
Constellation: Modulation constellation. Constellation may be QPSK, 16-
QAM or 64-QAM
Hierarchy: DVB-T hierarchy can have the values 'None', 1, 2 or 4.
HP code rate: The FEC mode used for the high priority transport stream
LP code rate: The FEC mode used for the low priority transport stream
Cell ID: The cell ID is a number identifying the transmitter.
Detected mode: The detected OFDM mode
Detected guard: The detected guard interval
DVB-T2 L1 Pre Information
T2 Version: DVB-T2 Version:
1.1.1
1.2.1
1.3.1
Post scrambling: Informs if L1-Post scrambling is enabled, supported from
DVB-T2 v1.3.1
'True' or 'false'.
DVB-T2 profile: Determines current profile of DVB-T2 Signal:
Base
Lite (supported form DVB-T2 v1.3.1)
Base compatible with
Lite:
Indicates if the DVB-T2 Base Profile is compatible with
DVB-T2 Lite profile. If Base is incompatible with Lite one
has to specify correctly which profile should be used for
tuning: Base or Lite. If there is compatibility between
both DVB-T2 profiles the tuning will be successful with
any of them.
'True' or 'False'
Type: The stream type contained within the current T2 super-
frame.
TS (Transport stream only)
GS (Generic streams only)
Mixed TS and GS
