The OFDM mode (DFT size). Possible OFDM modes are
1K, 2K, 4K, 8K, 16K and 32K
BW extended: Bandwidth extension indicator (only for 8K/ 16K/ 32K)
True or False
S1: S1 Signalling. P1 S1
0 – SISO (Single input, single output)
1 – MISO (Multiple input, Signle output)
2 – Non DVB-T2
S2: S2 Signalling. P1 S2
0 – DVB-T2 2K mode with any guard
2 – DVB-T2 8K mode with DVB-T guard.
4 – DVB-T2 4K mode with any guard.
6 – DVB-T2 1K mode with any guard.
8 – DVB-T2 16K mode with any guard.
10 – DVB-T2 32K mode with DVB-T guard.
12 – DVB-T2 8K mode with DVB-T2 guard.
14 – DVB-T2 32K mode with DVB-T2 guard.
Mixed: Mixed signalling indicator.
0 – Not mixed.
1 – Mixed (from S2 field).
FFT Mode: Specifies window size of Fast-Fourier-Transform (from S2
signalling).
“1K”, “2K”, “4K”, “8K”, “16K”, “32K”
L1 Repeat: L1 repeat enable flag.
“True” or “False”.
GI: The guard interval used for the current super-frame.
“1/4”, “1/8”, ”1/16”, “1/32”, “1/218”, “19/128”, “19/256”
PAPR: Peak to average power ratio indicator.
“None”,
“ACE”,
“TR”,
“TR-ACE”
L1 post constellation: The L1-post modulation in the current frame.
“BPSK”, “QPSK”, “16-QAM”, “64-QAM”.
L1 post Code Rate: The L1-post code rate in this frame.
PROBE USERS' MANUAL VERSION 5.0
