“1/2”
L1 post FEC: The L1-post FEC (Forward Error Correction) type.
“16K LDPC (Low-density parity-check).”
L1 post size: Size of the L1-post in OFDM cells.
L1 post info size: L1-post info size = L1-post configurable + dynamic +
extension.
PP: The pilot pattern for the OFDM symbols in this frame.
“1”, “2”, “3”, “4”, “5”, “6”, “7”, “8”.
TX ID availability: The TX id.
Cell ID: The T2 cell Id.
Network ID: The T2 network Id.
System ID: The T2 system Id.
Number frames: Number of T2-frames per T2 super-frame.
Number symnbols: Number of OFDM symbols per T2-Frame.
Regen: Regeneration count indicator.
Post ext: L1-post extensions enabled.
Number RF Freqs: The number of RF frequencies in use.
RF Index: The current RF index.
PLP count: Number of PLPS (Physical Layer Pipes)
DVB-T2 L1 PLP Information:
Id: The PLP (Physical Layer Pipe) Id.
Type: The type of the PLP.
“Common type”,
“Data 1”,
“Data 2”.
Group id: The group of PLPs that this PLP belongs to.
Constellation: The constellation of the current PLP.
“QPSK”, “16-QAM”, “64-QAM”, “256-QAM”.
Code rate: The code rate of this PLP.
“1/2”, “2/3”, “3/5”, “3/4”,
“4/5” - DVB-T2 Base only,
“5/6” - DVB-T2 Base only,
“1/3” - DVB-T2 Lite only,
PROBE USERS' MANUAL VERSION 5.0
