“2/5” - DVB-T2 Lite only.
Rotated: Indicates if constellation is rotated.
“True” or “False”.
FEC: The FEC (Forward Error Correction) type used on this PLP.
“LDPC (Low-density parity-check) 16K (Short
FECFrame)”,
“LDPC (Low-density parity-check) 64K (Long FECFrame)”.
- DVB-T2 Base Only.
Num blocks: Maximum number of PLP blocks.
Frame interval: The T2 frame interval within the super frame of this PLP.
Time interleaver
length:
Time interleaver length.
Time interleaver type: Indicates type of Time Interleaver.
In band A signalling: In-band A flag. Indicates whether PLP carries in-band
signalling.
“True” or “False”.
In band B signalling: In-band B flag, Indicates whether PLP carries in-band
signalling.
“True” or “False”.
In band B TS rate: In-band B signalling TS rate.
Payload: The payload carried by the PLP.
“GFPS (Generic Fixed-length Packetized Stream)”,
“GCS (Generic Continuous Stream)”,
“GSE (Generic Encapsulated Stream)”,
“TS (Transport Stream)”
Null packet detection: Null packet detection indicator.
“True” or “False”.
ISSY: Input Stream Synchronization Indicator.
“True” or “False”.
Mode: PLP (Physical Layer Pipe) Mode.
“HEM (High Efficiency Mode)”, “Normal”:
DVB-T2 L1 Post Information
Sub Slices per frame: The number of sub-slices per T2 Frame.
PLP count: The number of PLPs (Physical Layer Pipes) in the current
super frame.
Aux count: Number of auxillary streams.
