Appendix B - Drawings
B-4 P/N M/97-520
Figure B-4:230 VAC Wiring Diagram for IP 55 Groschopp Motor
DOCUMENT NO.
PAGE NO.
REV. NO.
TITLE
CREATED BY
APPROVED BY
DATE CHK. BY
DATE
230V WIRING DIAGRAM FOR
CA1-047
1 OF 1
9/9/96
IP 55 GROSCHOPP MOTOR
GREEN/YELLOW EARTH GROUND
BLUE NEUTRAL
CAPACITOR
"SNAP DISC" TYPE)
SWITCH (FENWAL
OPTIONAL TEMP.
U V W
BLACK
REVERSE RED & BLACK LEADS.
NOTE: TO REVERSE ROTATION,
C.W. ROTATION VIEWING FROM TOP
GROSHCOPP T.E.N.V. MOTOR IP 55 RATED
WHITE
RED
GREEN
SWITCH ASSEMBLY
OPTIONAL CIRCUIT BREAKER
ON/OFF
SWITCH
BROWN LIVE
INPUT
230V/60HZ
230V/50HZ
OR
KFM
NOTE:
THIS DRAWING SUPERCEDES DWG. #81-0106
6 M.F.D. - 3000 RPM
5 M.F.D. - 1500 RPM
JRM
1
12/18/97
