TT100 In-Line Viscometer Installation, Operation, Maintenance and Service Instructions
P/N M/97-520 6-13
19. Remove the Teflon gasket.
NOTE: Depending upon the application, the viscometer may contain none,
1, or 2 insulators.
CAUTION
Do not bend or damage the torsion element wire or when removing the
insulators.
20. Using a hex wrench, remove the insulator(s), gasket(s), and
mounting screws as required.
21. Using a mallet and a center punch, tap the torsion element flange to
remove the torsion element. Discard the torsion element.
22. Remove the shipping guards from the new torsion element.
23. Proceed with Sensing Endcap Assembly.
Sensing Endcap Assembly
CAUTION
Do not bend the torsion element center wire or otherwise damage the tor-
sion element when assembling the viscometer.
1. Insert the O-ring into the groove of the torsion element.
2. Insert the torsion element into the endcap and rotate the torsion
element so that the stator screws line up with the stop post correctly
as shown in Figure 6-7.
3. Place a teflon gasket on the torsion element flange.
4. Place the insulator on top of the teflon gasket and align the
mounting screw holes.
