TT100 In-Line Viscometer Installation, Operation, Maintenance and Service Instructions
P/N M/97-520 2-5
Figure 2-2:NEMA 4 - 115 or 230 VAC 50/60 Hz Installation
MOTOR
CONTROL
ENCLOSURE
TORQUE SENSOR
ENCLOSURE
ELECTRONICS
MOTOR POWER CABLE
SENSING CABLE
POWER CABLE
POWER CABLE
NOTE: REFER TO DRAWING NUMBER CA1-001 (115 VAC) OR CA1-047 (230 VAC) IN
APPENDIX B FOR ELECTRICAL CONNECTIONS.
CUSTOMER SUPPLIED 4 - 20 mA OUTPUT SIGNAL CABLE
