TT100 In-Line Viscometer Installation, Operation, Maintenance and Service Instructions
P/N M/97-520 5-9
6. Turn power to the motor controller enclosure OFF.
CAUTION
Do not damage the torsion element when installing the drive endcap
assembly into the measuring chamber.
7. Refer to Section 3 - Calibration and perform the calibration
procedures shown in Figure 3-2.
Elliptical Baffle Precautions
NOTE: The following information only applies to viscometers that are
equipped with the optional elliptical baffle.
The optional elliptical baffle is installed on viscometers at the factory. The
baffle is held in position by a slight compression between endcaps and will
become loose as endcap mounting screws are removed. The baffle will be
withdrawn from the measuring chamber along with the drive endcap and
must be installed with the drive endcap.
CAUTION
The elliptical baffle must be oriented within the measuring chamber so that
it does not bisect the inlet/outlet pipe. Make sure the baffle is positioned
properly prior to final tightening of the endcap mounting screws during
reassembly.
