Specifications
The TT100 In-Line Viscometer is available in standard or optional
configurations as listed in Table 1-1.
Table 1-1: Model TT100 In-Line Viscometer Specifications
Parameter Standard Configuration Optional Configuration*
Viscosity Range
(See Note 1)
10 - 500,000 cP 10 - 500,000 cP
Shear Rate Range
10 - 1000 sec
-1
0.02 - 12,000 sec
-1
Temperature Range
(See Note 2)
-40º - 300º F -40º - 500º F
Pressure Range
(See Note 3)
0 - 200 psi Vacuum to 500 psi
Reproducibility ± 0.5% of span ± 0.5% of span
Signal Output 4 - 20 mA 0 - 20 mA, 0 - 10 VDC
Power Requirements 115VAC 50/60Hz
100 Watts
230VAC 50/60 Hz
100 Watts
Chamber 300 Series S/S
1 inch NPT (Female)
inlet and outlet
316 S/S wetted parts
construction
1, 1 1/2, or 2 inch threaded or
flanged, 4 inch flanged
Motor Single-speed synchronous Multiple-speed with speed
control
Dimensions 5 x 5 x 17 inches
(127 x 127 x 431.8 mm)
5 x 5 x 17 inches
(127 x 127 x 431.8 mm)
Construction NEMA 4
Water tight and dust tight
Refer to Appendix D
Weight 50 lbs. (23 kg) 50 lbs. (23 kg)
* Optional Configurations offer dual range capability, custom mounting and/or special viscosity ranges and shear
rates.
NOTE 1: Range is calibrated with a 0 cP lower limit. The upper limit can be any value between 10 - 500,000 cP.
NOTE 2: Under certain conditions, temperatures as high as 700º F may be accommodated.
NOTE 3: Under certain conditions, pressures as high as 1000 psi may be accommodated.
