In-Line Viscometer Description
1-8 P/N M/97-520
Required Utilities
The TT100 In-Line Viscometer requires the utility connections listed in
Table 1-2 to operate.
Current Draw - Starting & Running
The normal running power requirement for TT100 In-Line Viscometer is
100 watts. However, the instantaneous starting current requirement for the
TT100 drive motor can be at least five times greater.
Brookfield Engineering Laboratories, Inc. recommends that any inverter,
transformer, or similar device that is used with the Model TT100 should be
rated at 750 volt-amperes or greater.
Table 1-2: Utility Requirements
Parameter Value
Supply Voltage 115/230 VAC
Line Frequency
(See Note 1)
50 or 60 Hz
Power 100 Watts
Flushing Requirements
(See Note 2)
3 - 10 gpm
30 - 40 psig
1/8 inch pipe thread endcap connection
Barrier Fluid Pressure
(See Note 3)
20 psi above maximum process flow pressure
NOTE 1: Variations in line frequency will affect instrument span and accuracy.
NOTE 2: If viscometer is equipped with flushing option.
NOTE 3: If viscometer is equipped with double mechanical seals.
